DigiMAX - Interface para modos digitalesHrd Version 5.24.38 Download
(por SM2YER) (traducido por CX8ABF)
Soldier of fortune payback manual. Interface SONIDO / PTT / CI-V Level Rig2pc para modos digitales,
con las siguientes funciones:
Jan 5, 2018 - Open.spotify.com 2014 Forest Hills Drive by J. Cole on Spotify 640 × 640 - 92k abouttoblow.com J. Cole - 2014 Forest Hills Drive| Album. Jan 2, 2018 - Cole Forest Hills Drive Live From Fayetteville NC album, JCole Forest Hills Drive Live, JCole Forest Hills Drive Live mp3 songs, download. J cole forest hills drive album download sharebeast.
Hrd Version 5.24.38 Free Download
- Audio - Aislamiento galvánico entre la Soundcard el equipo usando transformadores.
- PTT - Aislamiento usando un optoacoplador tipo 4N33.
- CI-V level - Interface de control del transceptor usando un integrado 'MAX232'.
- Front panel -
DigiMAX - Revision 2007.05.19 Changed pcb layout, it's now a little smaller to fit into the new box.
Also got a 'power led' and a new 'Front' panel layout. The PCB Layout files is updated to rev. 2007.05.19
- Making the DigiMAX interface -
Here is a complete description of the interface, with schematics, PCB-Layout and component list.
ready for you to use free of charge!
Closeup of DigiMAX PCB component side. rev. 2007.05.19
Closeup of BCB component side. rev. 2007.05.19
- Schematics / Components -
Interface Schematics. (OLD VERSION)
Hrd Version 5.24.38 Download
- PCB Layout -
This is the latest PCB layout files. rev. 2007.05.19
SOUND/PTT/CI-V PCB size is 110 x 60 millimeter - Layout in High resolution rev. 2007.05.19
High resolution Audio/PTT/CI-V PCB layout (In 539Kb 600x600dpi .jpg file)
(Ready to print on 115x65mm board)
In addition there is also a layout for a ' pc-sound="" to="" rig="" interface="" only'="" available="" on="" the="" 'old="" page'="" if="" the="" ci-v="" part's="" not="" needed="">
You can read more about making your own printed circuit boards -->Here!
- Component placement -
This is the PCB with the corrected layout with C6 and C8 in the correct places. (PLED is missing in this drawing. Refere to images of component side for component placement)
Component side of PCB with component placement (OLD VERSION)
Component placement - High resulotion (330K .pdf file)
- Internal wire hookup -
Drawing of the internal wire hookup to transceiver (TRCV) and PC
Internal wire hookup (OLD VERSION)
